Pull-out Tall-unit 5 Layers Basket, St.St. 304

Pull-out Tall-unit 5 Layers Basket, St.St. 304

Cabinet width mm
Features
  • Material of Basket: Stainless steel 304
  • Finish: Frame grey, stainless steel polished
  • Load capacity: 70 kg
  • Version: Center mounted, full extension soft close
  • Height adjustable: 1,770–2,070 mm
  • Basket position adjustable
  • Min. internal cabinet depth: 500 mm

Supplied with:

  • 2 pcs. runners, 1 pc. frame, 1 set front brackets, 5 baskets with support, 1 set fixing screws, 5 pcs. dividers

Front pull-out basket (450 mm runner)

    Cabinet width
    mm    		 Basket Dim. (WxDxH) mm Cat. No.
    300 245x480x1,770 - 2,070 mm 548.93.113
    400 245x480x1,770 - 2,070 mm 548.93.133
