Loox LED driver Loox LED driver Constant voltage 12 V
Loox LED driver Loox LED driver Constant voltage 12 V
Loox LED driver Loox LED driver Constant voltage 12 V
Loox LED driver Loox LED driver Constant voltage 12 V
Loox LED driver Loox LED driver Constant voltage 12 V
Loox LED driver Loox LED driver Constant voltage 12 V
Loox LED driver Loox LED driver Constant voltage 12 V

Loox LED driver Loox LED driver Constant voltage 12 V

Regular price
Temporarily sold out
Sale price
₱1,054.01
Tax included. Shipping calculated at checkout.

Features:

The driver is the heart of the Loox system, and is suitable for connecting to all of the worlds most frequently used mains voltages
and frequencies. All of the switches in the Loox product range can be connected to the drivers with a universal switch input.

All drivers are energy efficient and equipped with overload protection.

> Lead length from driver to switch max. 6 m.
> Driver available in white on request.
> Provide for sufficient air supply and circulation at the mounting location of the driver.

Note:

Power plug and Switch not include (Sold separately).

Cat. No. 833.74.960 833.74.962 833.74.913 833.74.941
Power output (W) 0 – 20 0 – 40 0 – 60 0 – 15
Input voltage 100 – 240 V~;
50 – 60 Hz
100 – 240 V~;
50 – 60 Hz
100 – 240 V~;
50 – 60 Hz
100 – 240 V~;
50 – 60 Hz
Output voltage DC 12 V DC 12 V DC 12 V DC 12 V
Output current 1.67 A 3.33 A 5 A 1.25 A
Standby power
consumption (W)
<0.1 <0.1 <0.5 W <0.5
Degree of protection IP20 IP20 IP20 IP20
Number of connections 6 x consumer,
1 x switch
6 x consumer,
1 x switch
6 x consumer,
1 x switch
6 x consumers,
without switch connection
Colour Black Black Black Black
Dimensions (L x W x H mm) 140 x 50 x 16 190 x 60 x 16 208 x 56.5 x 30 128 x 50.5 x 14
Supplied with 1 driver with mounting accessories 1 driver with mounting accessories 1 driver with mounting accessories 1 driver with mounting accessories
