Base unit internal pull outs

Base unit internal pull outs

Description

Feature

• Material: Steel
• Finish: Runner galvanized, basket bright chrome plated, Icewhite
• Version: Bottom mounted conceal runner, full extension with SoftStopp
• Load capacity: 30 kg
• Internal carcase depth: Min. 500 or 510 mm
• Side panel thickness: 16 or 19 mm

Front pull-out

Cabinet width Dimension W x D x H Cat No.
Inside cabinet width min. 412–418 mm
450 403 x 491 x 165 540.24.294
Inside cabinet width min. 462–468 mm
500 453 x 491 x 165 540.24.295
Inside cabinet width min. 562–568 mm
600 553 x 491 x 165 540.24.297

       Internal pull-out

      Cabinet width Dimension W x D x H Cat No.
      Inside cabinet width min. 412–418 mm
      450 377 x 488 x 125 540.27.294
      Inside cabinet width min. 462–468 mm
      500 427 x 488 x 125 c
      Inside cabinet width min. 562–568 mm
      600 527 x 488 x 125 540.27.297
